14-18 1500 6in. with Magneride -alumunim-Stamped
BDS corrects steering geometry at the new taller ride height using a pair of high-strength CNC machined ductile cast iron steering knuckle design to work with factory tie rod ends to maintain steering angles for proper function and ESC compatibility.
- Includes shock relocation brackets to maintain factory Magneride shocks
- High clearance crossmember design maximizes ground clearance
- Robust steering knuckles maintain ESC system compliance
- High-strength replacement upper control arms provide durability and serviceability
- HD skid plate system improved offroad protection
- Multipoint differential relocation brackets to secure the front axle and improve CV angles
- Factory Protection Plus drivetrain warranty included
Information:
Factory 17" and 18" wheels cannot be reinstalled due to tie rod end interference.
Application Summary:
| Year |
Make/Model |
| 2015-2018 |
GMC Sierra 1500 |
| Attributes |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Country of Origin (Primary) |
US |
| Factory Control Arm Type |
aluminum stamped steel |
| Front Lift Height |
6 |
| Front Lift Method |
Cross Member |
| GTIN |
00840416420517 |
| Hazardous Material Code |
N |
| Installation Difficulty |
difficult |
| Installation Time |
8 Hrs |
| Installation Tools |
36mm Socket-Cut Off Wheel or Equiv-saw reciprocating-welder |
| Life Cycle Status Code |
Available to Order |
| NAFTA Preference Criterion Code |
B |
| Rear Lift Height |
5 |
| Rear Lift Method |
Block |
| SDR Required Flag |
N |
| Shocks Included |
No |
