X-Series Long Arm Suspension Lift Kit w/Shocks; 4.5 in. Lift;
Take your XJ's already capable platform to the next level with Rough Country's 4.5 inch Long arm suspension kit. This fully bolt on kit relocates the front control arms to achieve optimum alignment angles, while giving your rig insane articulation off road. A set of Rough Country's premium N3 shocks are also included. These fine tuned 10-stage variable high-pressure Nitrogen charged shocks offer a fantastic blend of off-road action and smooth highway ride quality. With a durable 18mm spring-loaded piston rod and faster-cooling 54mm shock body. You get top quality craftsmanship, and superior off road capability all for an unbeatable value and the best price in the market!
- Lower control arms feature high clearance design Extreme travel long arms keep optimum alignment and give optimum articulation
- X-Flex control arm features: Clevite brand OEM style rubber bushings
- Flex joints feature a massive 2.5" diameter body and 1.25" thread
- Fully greaseable
- Upper joints pivot up to 20 degrees
- Lower joints pivot up to 35 degrees.
- Unbeatable value and the best price in the market! Aggressive appearance
- Increased ground clearance
- Front adjustable track bar is made of forged solid steel for unsurpassed strength and durability Quick disconnects quickly and easily store out of the way when not in use
Information:
ONLY fits models with NP231 transfer case. Does NOT fit models with 2.8L V-6 engine. Does NOT fit models diesel engine. Does NOT fit 87-89 models with Peugeot manual transmissions. If running 33" tires, they will require fender trimming to clear.
Application Summary:
| Year |
Make/Model |
| 1984-2001 |
Jeep Cherokee |
| Attributes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Category |
Susp Lift Kits 4wd |
| Country of Origin (Primary) |
US |
| Front Components |
Lifted high flex coil springs, Long arm Crossmember, Adjustable upper control arms, Adjustable lower control arms, Long arm Crossmember, Transfer case skid plate, Sway-bar quick disconnects, Forged adjustable track bar, Pitman arm, Stainless steel braided brake lines, Hardware |
| Front Kit Componenets |
Lifted high flex coil springs, Long arm Crossmember, Adjustable upper control arms, Adjustable lower control arms, Long arm Crossmember, Transfer case skid plate, Sway-bar quick disconnects, Forged adjustable track bar, Pitman arm, Stainless steel braided brake lines, Hardware |
| Front Kit Components |
Lifted high flex coil springs, Long arm Crossmember, Adjustable upper control arms, Adjustable lower control arms, Long arm Crossmember, Transfer case skid plate, Sway-bar quick disconnects, Forged adjustable track bar, Pitman arm, Stainless steel braided brake lines, Hardware |
| GTIN |
00843030124533 |
| Harmonized Tariff Code (Schedule B) |
8708809900 |
| Hazardous Material Code |
N |
| Install Time |
8-9 hours |
| Life Cycle Status Code |
Available to Order |
| Lift/Drop Height |
4.5 in. |
| NAFTA Preference Criterion Code |
B |
| Rear Components |
Add-a-leaf springs, Adjustable lift shackles, U-bolts, Stainless steel braided brake line, Hardware |
| Rear Kit Components |
Add-a-Leaf springs, Adjustable lift Shackles, U-Bolts, Stainless steel braided brake line, Hardware |
| SDR Required Flag |
N |
| Shipping Options |
No Restrictions |
| Ships in Multiple Boxes |
Y |
| Tire, Wheel, and Offset Info |
32x11.50R15:15x8:5x4.5:-19:-; 32x11.50R15:15x8:5x4.5:-18:-; 32x11.50R15:15x8:5x4.5:-12:-; 32x11.50R15:15x8:5x4.5:-6:-; 285 75R16:16x8:5x4.5:-19:-; 285 75R16:16x8:5x4.5:-18:-; 285 75R16:16x8:5x4.5:-12:-; 285 75R16:16x8:5x4.5:-6:-; 285 70R17:17x8:5x4.5:-19:-; 285 70R17:17x8.5:5x4.5:-12:-; 285 70R17:17x8.5:5x4.5:+0:-; 285 70R17:17x8.5:5x4.5:+1:-; 285 70R17:17x9:5x4.5:+0:-; 285 70R17:17x9:5x4.5:+1:-; 285 65R18:18x8:5x4.5:-19:-; 285 65R18:18x8.5:5x4.5:+0:-; 285 65R18:18x8.5:5x4.5:+1:-; 285 65R18:18x9:5x4.5:+0:-; 285 65R18:18x9:5x4.5:+1:-; 33x11.50R20:20x8:5x4.5:-19:-; 33x11.50R20:20x9:5x4.5:+0:-; 33x11.50R20:20x9:5x4.5:+1:- |
