Suspension Lift Kit w/Shocks; 4 in. Lift; Incl. Lifted N3 Struts; Premium N3 Shocks;
Give your RAM 1500 the perfect blend of performance, protection, and style with Rough Countrys 4- in. Suspension Lift. Designed to offer an affordable way to maximize off-road performance and run up to 35- in. tires, these kits offer high quality, heavy-duty equipment for new model RAM 1500s. Utilizing heavy-duty, laser cut, steel equipment engineered by Rough Country, these 4- in. Suspension Lifts are complete kits that include everything needed for outstanding off-road performance. High-clearance front and rear cross-members provide enough room for off-road climbs and runs. A heavy-duty skid plate shields the vehicles differential, protecting you from hazardous terrain. A durable set of driver and passenger side lifted cast knuckles are also included, helping to promote proper geometry once the vehicle is lifted. For true trailblazers, this kit also ships with a set of rear N3 Nitrogen-charged shock absorbers - valved specifically for a blend of on and off-road performance. Includes Rough Countrys Lifetime Replacement Guarantee!
- Increased Ground Clearance
- Maintains Factory Track Width
- Levels The Front With The Rear Of The Vehicle
Information:
Requires 20in or larger wheels! Does NOT fit 18in or smaller wheels
Application Summary:
| Year |
Make/Model |
| 2012-2018 |
Ram 1500 |
| 2019-2023 |
Ram 1500 Classic |
| Attributes |
| California Proposition 65 |
No |
| Country of Origin (Primary) |
US |
| Front Components |
Lifted knuckles, Front crossmember, Rear crossmember, Differential drop brackets, Driveshaft spacer, Sway-bar links, Skid plate, Hardware |
| Front Kit Componenets |
Lifted knuckles, Front crossmember, Rear crossmember, Differential drop brackets, Driveshaft spacer, Sway-bar links, Skid plate, Hardware |
| Front Kit Components |
Lifted knuckles, Front crossmember, Rear crossmember, Differential drop brackets, Driveshaft spacer, Sway-bar links, Skid plate, Hardware |
| GTIN |
00843030176877 |
| Harmonized Tariff Code (Schedule B) |
8708809900 |
| Hazardous Material Code |
N |
| Install Time |
4-6 hours |
| Life Cycle Status Code |
Available to Order |
| Lift/Drop Height |
4 in. |
| NAFTA Preference Criterion Code |
B |
| Rear Components |
Upper coil spacers, Sway-bar links, Bump-stop brackets, Brake line brackets, Hardware |
| Rear Kit Components |
Upper coil spacers, Sway-bar links, Bump-stop brackets, Brake line brackets, Hardware |
| SDR Required Flag |
N |
| Tire, Wheel, and Offset Info |
35x12.50R20:20x9:5x5.5:-12:-; 35x12.50R20:20x9:5x5.5:+0:Minor trimming; 35x12.50R20:20x9:5x5.5:+0:-; 295 60R20:20x9:5x5.5:+0:-; 35x12.50R20:20x9:5x5.5:+1:Minor trimming; 35x12.50R20:20x9:5x5.5:+1:-; 295 60R20:20x9:5x5.5:+1:-; 35x12.50R20:20x10:5x5.5:-25:-; 35x12.50R20:20x10:5x5.5:-24:-; 35x12.50R20:20x10:5x5.5:-19:-; 295 60R20:20x10:5x5.5:-19:-; 35x12.50R20:20x10:5x5.5:-18:-; 35x12.50R22:22x10:5x5.5:-25:-; 35x12.50R22:22x10:5x5.5:-24:-; 35x12.50R22:22x10:5x5.5:-19:-; 35x12.50R22:22x10:5x5.5:-19:Minor trimming; 35x12.50R22:22x10:5x5.5:-18:Minor trimming; 35x12.50R22:22x10:5x5.5:-18:- |
