Suspension Lift Kit; 6 in. Lift; Upper Strut Spacers; Skid Plate; Front/Rear Cross Member; Sway Bar Drop Brackets; Fabricated Anti-Wrap Lift Blocks; Stock Cast Steel;
Get the look you really want with Rough Countrys 6- in. Suspension Kit for GMC Sierra Denali 1500 Pickups equipped with Magnetic Ride Control. This massive kit affords your truck the ability to run 33- in. tires on factory wheels with our beefy lifted knuckles and is designed with 100% laser-cut materials for the best possible fit on your vehicle.Includes a set of front and rear high-clearance crossmembers featuring the in.RC in. logo and a differential skid-plate. Each kit also comes with a set of durable, fabricated lift blocks that are stronger and offer a longer lifespan than cast blocks.Give your pickup an aggressive, lifted and level stance with incredible ride quality! Our innovative Lifted Knuckle design boosts ride height while keeping all components at the optimum angles for a factory-like ride. Includes Rough Countrys Lifetime Replacement Warranty.
- Can run 33-inch tires on factory 20-inch wheels
- Provides Highly Sought Level Stance
- High Clearance Crossmember Design Give Unmatched Ground Clearance
- 100 Pct. Precision Laser Cut Materials
- No Need To Disassemble Your Struts To Install
- Re-Uses Stock Front Skid Plat
Information:
Requires cutting and drilling
Application Summary:
| Year |
Make/Model |
| 2014-2018 |
GMC Sierra 1500 |
| Attributes |
| California Proposition 65 |
No |
| Country of Origin (Primary) |
US |
| Front Components |
Lifted knuckles, Front crossmember, Rear crossmember, Upper strut spacers, CV spacers, Differential drop brackets, Differential skid plate, Sway-bar drop brackets, Hardware |
| Front Kit Componenets |
Lifted knuckles, Front crossmember, Rear crossmember, Upper strut spacers, CV spacers, Differential drop brackets, Differential skid plate, Sway-bar drop brackets, Hardware |
| Front Kit Components |
Lifted knuckles, Front crossmember, Rear crossmember, Upper strut spacers, CV spacers, Differential drop brackets, Differential skid plate, Sway-bar drop brackets, Hardware |
| GTIN |
00843030173319 |
| Harmonized Tariff Code (Schedule B) |
8708809900 |
| Hazardous Material Code |
N |
| Install Time |
8-10 hours |
| Life Cycle Status Code |
Available to Order |
| Lift/Drop Height |
6 in. |
| NAFTA Preference Criterion Code |
B |
| Rear Components |
Fabricated lift blocks, Brake line brackets, U-bolts, Hardware |
| Rear Kit Components |
Fabricated lift blocks, Brake line brackets, U-bolts, Hardware |
| SDR Required Flag |
N |
| Tire & Wheel Size Combinations |
305/55 R20 - 20x9, Offset: +12 to +18mm (Models equipped with Factory 18-inch or larger wheels must run 18-inch or larger wheels if changing to aftermarket wheels), 305/55 R20 - 20x9, Offset: +12 to +18mm (Models equipped with Factory 18-inch or larger wheels must run 18-inch or larger wheels if changing to aftermarket wheels) |
| Tire, Wheel, and Offset Info |
295 70R17:Factory 17:6x5.5:-:-; 295 55R20:Factory 20:6x5.5:-:0.25 Spacer; 285 65R18:Factory 18:6x5.5:-:-; 305 70R17:17x9:6x5.5:+12:-; 305 70R17:17x9:6x5.5:+18:-; 285 70R17:17x9:6x5.5:+18:-; 305 65R18:18x9:6x5.5:+12:-; 305 65R18:18x9:6x5.5:+18:-; 285 65R18:18x9:6x5.5:+18:-; 285 65R18:18x9:6x5.5:+19:-; 285 65R18:18x9:6x5.5:+20:-; 305 55R20:20x9:6x5.5:+12:-; 305 55R20:20x9:6x5.5:+18:-; 295 60R20:20x9:6x5.5:+18:-; 305 55R20:20x9:6x5.5:+20:-; 295 60R20:20x9:6x5.5:+20:- |
