Max-E-Loader Class IV Trailer Hitch; Rear; 2 in. Receiver; 600/6000 lbs. Weight Carrying [Tongue Weight/Gross Trailer Weight];
Draw-Tite custom-fit hitches are built according to manufacturer vehicle weight specifications and model year to ensure a perfect fit and top towing performance. Featuring solid all-welded construction for maximum strength and safety, every hitch meets and exceeds industry standards. 2" Square Receiver Tube Opening Max-E-Loader receivers are designed for trucks, vans and sport utility vehicles The longer side bracket design distributes the towing load over a greater portion of the tow vehicle frame Neat Appearance, All Frame Attachments E-Coat Base w/ Black Powder Coat Finish Rated up to 6,000 lbs. (GTW) Weight Carrying (WC)Rated up to 10,000 lbs. (GTW) Weight Distributing (WD) Solid All-Welded Construction for Maximum Strength and Safety Custom Built According to Manufacturer & Model Year Ensures Perfect Fit and Top Towing Performance Computer-Aided Design and Fatigue Stress Testing Designed to Withstand Road Abuse Within Specified Capacities Backed by a Nationwide Limited Lifetime Warranty
Draw-Tite custom-fit hitches are built according to manufacturer vehicle weight specifications and model year to ensure a perfect fit and top towing performance. Featuring solid all-welded construction for maximum strength and safety, every hitch meets and exceeds industry standards. 2" Square Receiver Tube Opening Max-E-Loader receivers are designed for trucks, vans and sport utility vehicles The longer side bracket design distributes the towing load over a greater portion of the tow vehicle frame Neat Appearance, All Frame Attachments E-Coat Base w/ Black Powder Coat Finish Rated up to 6,000 lbs. (GTW) Weight Carrying (WC)Rated up to 10,000 lbs. (GTW) Weight Distributing (WD) Solid All-Welded Construction for Maximum Strength and Safety Custom Built According to Manufacturer & Model Year Ensures Perfect Fit and Top Towing Performance Computer-Aided Design and Fatigue Stress Testing Designed to Withstand Road Abuse Within Specified Capacities Backed by a Nationwide Limited Lifetime Warranty
- Max-E-Loader Class IV Trailer Hitch
Information:
Max-E-Loader Class IV Trailer HitchApplication Summary:
| Year | Make/Model |
|---|---|
| 1988-1999 | Chevrolet C1500 |
| 1988-2000 | Chevrolet C2500 |
| 1988-2000 | Chevrolet C3500 |
| 1988-1999 | Chevrolet K1500 |
| 1988-2000 | Chevrolet K2500 |
| 1988-2000 | Chevrolet K3500 |
| 1988-1999 | GMC C1500 |
| 1988-2000 | GMC C2500 |
| 1988-2000 | GMC C3500 |
| 1988-1999 | GMC K1500 |
| 1988-2000 | GMC K2500 |
| 1988-2000 | GMC K3500 |
| Attributes | |
| Country of Origin (Primary) | MX |
| Emission Code | Legal US |
| GTIN | 00742512415247 |
| Gross Trailer Weight | 6000 lbs. |
| Gross Trailer Weight (lbs.) | 6000 |
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| NAFTA Preference Criterion Code | B |
| Position | Rear |
| SDR Required Flag | N |
Draw-Tite 41524 Class IV Trailer Hitch
Product Information
- Brand: Draw-Tite
- Product Number: 41524
