CURT 57676 4-Way Flat Vehicle-Side to 7-Way RV Blade Trailer Wiring Adapter with Tester

---

There are several different types of connectors used to supply power from a tow vehicles electrical system to a trailers wiring system. Some trailers only need the bare essentials -- running lights, brake lights and turn signals -- while others require a connection for reverse lights, electric brakes and auxiliary power. With connectors ranging from simple to complex, it may be the case that the connection between your vehicle and your trailer is not a perfect match. For example, your truck may be equipped with a 6-way round socket, but your trailer may have a 4-way flat plug. For this very common problem, CURT offers a quick and simple solution in the form of an electrical adapter. An adapter is an electrical device that allows a connection to be made between a mismatched trailer plug and vehicle socket. It easily plugs in your vehicles electrical socket and usually requires no additional wiring. CURT offers an array of adapters to accommodate most types of plugs and sockets, including 4-way flat, 4-way round, 5-way flat, 6-way round, 7-way RV blades and more. This electrical adapter is designed to adapt a 4-way flat vehicle socket to fit a 7-way RV blade trailer plug. Some manual wiring is required. It comes with an integrated electrical tester, a mounting bracket and all necessary hardware for a complete installation. All CURT wiring and electrical products come with a one-year limited warranty to give you the assurance you need to tow with confidence.

• Adapts A 4-Way Flat Socket To Fit 7-Way Blade Trailer Plugs
• Simple Plug-And-Play Design For Easy Installation
• 7-Way Connects Tail Brake Reverse Turn Signals Brakes
• Integrated Led Tester Confirm Proper Vehicle And Trailer Function
• Spring-Loaded Dust Cover Keeps Connector Clean When Not In Use
• Slit Loom Keeps Wires Contained And Well Protected
• Bracket Securely Mounts Wiring To The Vehicle Or Trailer Hitch

---

Information:

Electrical Adapter with Tester (4-Way Flat Vehicle to 7-Way RV Blade Trailer); Adapts a 4-way flat vehicle socket to fit 7-way RV blade trailer plugs; Simple plug-and-play design for easy installation (some manual wiring required); 7-way connects tail, brake, reverse, turn signals, brakes and auxiliary power; Integrated LED tester confirms proper function of vehicle-side wiring connector; Spring-loaded dust cover keeps connector clean when not in use; Slit loom keeps wires contained and well protected; Metal bracket securely mounts wiring to the vehicle or trailer hitch

---

Application Summary:

Year	Make/Model
CURT	57676 4-Way Flat Vehicle-Side to 7-Way RV Blade Trailer Wiring Adapter with Tester
