CURT 16520 A16 5th Wheel Hitch Head Only; Legs or Roller Required; 16;000 lbs

---

The CURT A16 is designed to provide a surprisingly quiet ride while maintain superior towing power. It has a gross trailer weight capacity of 16,000 lbs. and can handle a vertical load up to 4,000 lbs. It comes with a three-position coupling indicator visible from your pickup truck cab, an extra wide head for easier coupling and high-strength interlocking die-cast jaws for a secure hold on your 5th wheel trailer. This 16K 5th wheel hitch excels in quiet 5th wheel towing. It uses a fully articulating torsion head, a cast yoke with poly-torsion inserts and interlocking jaws to create stability for your trailer and tow vehicle. These components also allow the A16 to suppress shock and vibrations and reduce any additional noise coming from your trailer. Like the other CURT A-Series hitches, the A16 is coated with a durable carbide powder coat finish. It is tested in accordance with SAE J2638 for safety and includes a limited lifetime warranty to make this the best hitch ever to be mounted in the back of your pickup. This A16 5th wheel hitch head comes ready to be attached to the CURT R16 5th wheel roller.

• Des. To Mount On The R16 Roller For Towing 16000-Lb. 5Th Wheels
• Extra Wide Head Opening For Easier Coupling
• Three-Position Coupling Indicator Is Clearly Visible From Truck
• Fast One-Pin Head Removal For Easy Disassembly
• Compatible w/Kingpin Extension Incl. Common Pivoting Pin Boxes
• Incl. A Polyethylene Lube Plate To Eliminate Messy Grease Deposit
• Meets Proposed SEA J2638 Testing Standards
• High-Strength Interlocking Cast Jaws Fully Wrap The Kingpin
• Articulating Head For Controlled Coupling And Stable Towing
• Cast Yoke w/Poly-Torsion Inserts Suppresses Shock And Noise
• Lockable Handle Self-Resets To The Ready-To-Couple Position

---

Information:

Compatible with kingpin extension boxes, including common pivoting pin boxes; Offers three height adjustment positions to adapt to each unique truck bed; Includes a polyethylene lube plate to eliminate messy grease deposits; Tested for safety in accordance with SAE J2638; Protected by a highly durable carbide powder coat finish; Limited lifetime warranty (one-year finish, one-year parts); A16 5th Wheel Hitch Head; Requires CURT 5th wheel roller or legs for installation; Cast yoke with poly-torsion inserts to suppress shock loads and reduce noise; Fully articulating torsion head for controlled coupling and stable towing; Lockable handle self-resets to the ready-to-couple position after uncoupling; High-strength, interlocking jaws fully wrap the kingpin to minimize noise; Extra wide head opening for easier coupling; Fast, one-pin head removal makes moving easy with smaller, lighter pieces; Three-position coupling indicator clearly shows coupling status

---

Application Summary:

Year	Make/Model
CURT	16520 A16 5th Wheel Hitch Head Only, Legs or Roller Required, 16,000 lbs
